FCM2-1808A-ABL4 – HTM Sensors M18 Inductive Proximity Sensor Unshielded 8 mm AC NO M12 B Coded Connector
by HTM
CALL or click FOR QUOTE
The HTM Sensors FCM2-1808A-ABL4 is an M18 unshielded inductive proximity sensor with a 8 mm sensing range, an AC normally open (NO) output, a 20-250 V AC supply and an M12 B Coded connector. Inductive proximity sensors detect metal targets without physical contact, making them a dependable choice for position and presence sensing on machinery, conveyors and automated equipment.
Key Specifications
| Part number | FCM2-1808A-ABL4 |
|---|---|
| Type | Inductive Proximity Sensor |
| Shape | Cylindrical |
| Size | M18 |
| Sensing range | 8 mm |
| Mounting style | Unshielded |
| Output type | AC |
| Output function | Normally Open |
| Connection | 4 Pin Quick Disconnect |
| Connector | M12 B Coded Connector |
| Body length | 79 mm |
| Housing | Chrome Plated Brass |
| Sensing face | PBT Plastic |
| Protection rating | IP67 |
| Operating temperature | -25 C - +70 C |
| Supply voltage | 20-250 V AC |
| Current consumption | <1.8 mA |
| Leakage current | <1.8 mA |
| Max current | 400 mA |
| Surge current | 5 A (20 ms) |
| Short circuit protected | NO |
| Reverse polarity protected | NO |
| Switching frequency | <25 Hz |
| Response time | 10 ms/10 ms |
| EMC rating | RFI>3V/m / EFT>1kV / ESD>4Kv (contact) |
| Shock/vibration rating | IEC 60497-5-2 Part 7.4.1&7.4.2 |
| Weld field immune | No |
| Weld spatter resistant | No |
| Matching cable | R-FS4TZ-V885 (Straight Connector) / R-FA4TZ-V885 (Angled Connector) |
| Matching bracket | HRAB-18 (Basic) / QT-18 (Quick Release) |
Condition, Warranty & Shipping
- Condition: Factory new
- Warranty: 1-year United Industries warranty
- Ships from: Jamestown, NY
Call for best price & availability: +1-800-724-4209
